Kamra tat-Test tat-Temperatura Kostanti Integrata

1.1 Mudell

TOB-HW-200-160CH

1.2 Model naming method

HW-200-8T S-160CH 110V

① ② ③ ④ ⑤ ⑥

Tifsira

①Integrated kostanti temperatura test kamra serje

②Capacity: 200L

③8T: 8 temperatura żoni (single temperature zone ma not show)

④Refrigeration method: S means semiconductor refriġeration (temperature range: 15 degree -60 degree )Compressor refrigeration does not show (temperature range: 0 degree -60} degree degree )

⑤160CH: 160 channel

⑥110V: tagħmir vultaġġ 110V (the default voltage is 220V, ma not show)

2. Prodott applikazzjoni

Kostanti temperatura test ta ' polimeru batterija u buttuna batterija.

Manifatturi ta' electronics, elettriku inġinerija, strumentazzjoni, materjali, semikondutturi, etc. conduct constant temperature tests on non-flammable and non-explosive items.

Environmental protection, agricultural and livestock, akkwatiku xjentifiku riċerka istituzzjonijiet u produzzjoni kumpaniji, etc., conduct constant temperature tests on water analysis, bacteria, mold, microbial cultivation, preservation, plant cultivation, breed, plant cultivation, and breeding experiments.

3. Kampjun limitu

Dan test tagħmir jipprojbixxi:

Test jew ħażna ta' fjammabbli, splussiv u volatili sustanzi

Test jew ħażna ta ' korrużiv materjal kampjuni

Test jew ħażna ta ' qawwi elettromanjetiku emissjoni sors kampjuni

Ittestjar u ħażna ta ' radjuattiv materjal kampjuni

Test u ħażna ta' ħafna tossiċi sustanzi

Test jew ħażna ta' kampjuni li jistgħu jipproduċu is-sustanzi jew oġġetti msemmija hawn fuq matul

ittestjar jew ħażna

4. Kapaċità, Dimens, Piż

4.1 Inner capacity

200L

4.2 Ġewwa dimensjonijiet

W500 * D500 * H800 mm

4.3 B'mod ġenerali dimensjonijiet

W700 * D1200 * H1500 mm

4.4 Nett piż

Madwar 220kg

5. Prestazzjoni

5.1 Ittestjar ambjent

Il ambjentali temperatura is + 25 degree , the relative humidity is Less than or equal to 85%, and there is no sample in the test chamber (no load)

5.2 Temperatura firxa

0-60 degree

5.3 Temperatura fluttwazzjoni

Inqas minn jew ugwali għal 1 grad (no tagħbija u stabbli temperatura)

5.4 Temperatura devjazzjoni

±2.0 grad (NO Load U Stable Temperature)

5.5 Tisħin ħin

25 grad →60 grad Less than or equal to 30 min

5.6 Tkessiħ ħin

25 grad →0 degree Less than or equal to 50 min

6. Struttura

6.1 Insulazzjoni struttura

Barra ħajt materjal: kwalità għolja kiesaħ irrumblat azzar pjanċa , wiċċ sprej u żebgħa trattament

Ġewwa ħajt materjal: stainless azzar platt SUS304

Kaxxa insulazzjoni materjal: polyurethane fowm (insulazzjoni ħxuna 50mm)

6.2

Arja kondizzjonament kanal

Axial fan, heater, evaporatur

6.3 Standard konfigurazzjoni

Door: Hollow anti-fog tempered glass + stainless steel frame

Ċomb toqba (b' soft gomma plug): φ50mm, 4pcs (jinsabu fuq il dahar ġenb tal kaxxa kaxxa)

Casters: 4 (bi brejk)

Kampjun rack: 4 layers of electrical insulation sample rack, load bearing (uniform distribution): 10kg/layer

Dawl: LED dawl

6.4 Kontroll pannell

Touch kontroll buttuni

6.5 Ħiter

Ħiter kontroll modalità: contactless, equal period pulse-width modulation, SSR (solidu state relay)

7. Refriġerazzjoni sistema

7.1 Refrigeration compressor

Kompletament magħluq pistun kompressur

7.2 Tkessiħ metodu

Imkessaħ bl-arja

7.3 Apparat Throttle

Kapillari tubu

7.4 Refriġerant

R134a

7.5 Iwweldjar proċess

Mimli nitroġenu protettiv iwweldjar

8. Elettriku kontroll sistema

8.1 Kontrollur

LED diġitali display + touch key controller

8.2 Setting modalità

Touch ċavetta

8.3 Kontroll modalità

Sfurzat ċirkolazzjoni ventilazzjoni. According to is-sett temperatura valur , il kontroll sistema kontrolli il - output ta ' il- ... heater permezz PID awtomatiku kalkolu , so as biex tikseb dinamika bilanċ.

8.4 Komunikazzjoni modalità

Ethernet standard interface

8.5 Temperatura kontroll modulu
